ترانزیستور MJE13009 پکیج TO-220

ترانزیستور MJE13009 پکیج TO-220 اورجینال

DESCRIPTION
The MJE13009 is designed for high-voltage, high-speed power switching inductive circuits where fall time is critical. They are particularly suited for 115 and 220V switch mode applications such as Switching Regulators, Inverters, Motor Controls, Solenoid/Relay drivers and Deflection circuits.

FEATURES
* VCEO 400V and 300 V
* Reverse Bias SOA with Inductive Loads @ TC = 100℃
* Inductive Switching Matrix 3 ~ 12 Amp, 25 and 100℃
tC @ 8 A, 100℃ is 120 ns (Typ).
* 700 V Blocking Capability
* SOA and Switching Applications Information.
