آپ امپ UA741CN پکیج DIP

آپ امپ UA741CN پکیج DIP

دیتاشیت

Manufacturer: Texas Instruments
Series: UA741CN / LM741CN
Product Category: Operational Amplifiers – Op Amps
RoHS: Details
Mounting Style: Through Hole
Package / Case: PDIP-8
Supply Voltage – Max: 36 V
Number of Channels: 1 Channel
GBP – Gain Bandwidth Product: 1 MHz
SR – Slew Rate: 0.5 V/us
CMRR – Common Mode Rejection Ratio: 70 dB to 90 dB
Ib – Input Bias Current: 500 nA
Vos – Input Offset Voltage: 5 mV
Supply Voltage – Min: 7 V
Operating Supply Current: 1.7 mA
Minimum Operating Temperature: 0 C
Maximum Operating Temperature: + 70 C
Shutdown: No Shutdown
Packaging: Tube
Amplifier Type: General Purpose Amplifier
Height: 4.57 mm
Length: 9.81 mm
Product: Operational Amplifiers
Supply Type: Dual
Technology: Bipolar
Width: 6.35 mm
Brand: Texas Instruments
Dual Supply Voltage: +/- 5 V, +/- 9 V, +/- 12 V, +/- 15 V
Maximum Dual Supply Voltage: +/- 18 V
Minimum Dual Supply Voltage: +/- 3.5 V
Operating Supply Voltage: +/- 3.5 V to +/- 18 V
Pd – Power Dissipation: 500 mW (1/2 W)
Product Type: Op Amps – Operational Amplifiers
